FyberOptix 4 Channels CWDM Mux or Demux, 1550-1610nm, with Expansion Port, 1.5dB Typical IL, LC/UPC, Single Fiber, FMU Plug-in Module

Description

Fyber Optix delivers fully tested, OEM-compatible optical transceivers, DWDM/CWDM systems, media converters and DAC/AOC cables — coded for Cisco, Huawei, Juniper, Arista, HPE, Dell, Nokia and Fortinet platforms, with lifetime warranty and fast global delivery.

The 4CH Mux Demux, based on TFF technology, is a passive CWDM device featuring high density, low loss, and short-haul transmission suitability. It is integrated with an expansion port, which supports expanding the capacity of existing fiber infrastructure. It utilizes 1550nm CWDM channels to transmit multiple DWDM wavelengths within a single CWDM channel, providing a cost-effective and easily scalable solution. In addition, this unit can act as a multiplexer or a de-multiplexer (Mux/Demux). It combines 4-channel of CWDM wavelengths into a composite signal or separates the combined CWDM signal into 4-channel individual wavelengths over a single-mode optical fiber. In accordance with the ITU-T G.694.2, it maximizes the capacity of the C-band range. Designed for maximum configuration flexibility, the CWDM Mux Demux can plug directly into the FMU chassis, each module occupying one slot.

Fyber Optix is a British-engineered brand of OEM-compatible optical networking products, including SFP, SFP+, QSFP+, QSFP28 and QSFP-DD transceivers, DWDM/CWDM systems, media converters, and DAC/AOC cables. Every module is 100% pre-shipment tested and coded for seamless compatibility with major platforms such as Cisco, Huawei, Juniper, Arista, HPE, Dell, Nokia and Fortinet — backed by a lifetime warranty, fast global delivery, and dedicated technical support for data centers, telecom operators, enterprise networks and system integrators worldwide.
