10GBASE-SR-ITEMP

Industrial Temperature SFP+ Transceiver Module

QuickSpecs

Technical Specifications

• 10GBASE-SR Small Form-factor Pluggable Plus (SFP+).
• Standards based 10-Gigabit Ethernet (10GBASE-SR).
• 10 Gbit/sec line speed.
• Operating distance up to 300m on OM4 fibre.
• Transmitter wavelength 850nm.
• Industry-standard LC duplex connector.
• Multimode Fibre (MMF).
• Digital Optical Monitoring (DOM).
• Extended temperature range (EXT): -40°C to 85°C (-4 to 185°F)

Compatibility

The GBICS 10GBASE-SR I-Temp transceiver can be coded for compatibility with over 100 vendors and 1000's of platforms.

Each individual transceiver is coded in-house. Please contact the sales team via email sales@gbics.com or call +44 (0) 1285 886444 to discuss your requirements.

Safety Standards

EN 60825-1 (2007)/EN 60825-2 (2010).
FDA 21CFR1040.10 Class 1 Laser Product.
Compliance with Restriction on Hazardous Substances (RoHS) directive.
CE Marked.
